Terpene Trap PROCESSING POWER:
4 gallon standard collection vessel; Heat exchange area: 21.64 sq ft; 1 HP standard chiller size; Relative vacuum rating: 0 to 27.8 “Hg

GMP COMPLIANCE:
UL 508A; Metals: 316 Stainless Steel; Polymers: Viton, Buna-N; FDA approved materials: International certifications

PROCESSING CONTROL:
Decarboxylation vapor recovery; Vacuum pump cold trap; Decreasing moisture carryover to ethanol; compatible with high CFM & low-pressure vacuum pumps

Additional Specs
Wall Mount Condenser System for Vacuum Ovens and manifold DrainDroyd apparatuses.
The condenser can collect and save terpenes for further refinement during decarboxylation, or protect vacuum pumps from volatiles in winterization, and filtration.

Supplied with United Science engineered kits and methods. Included equipment and tubing allows multiple ovens or DrainDroyds to be linked together to maximize the Condenser’s efficiency.

Also Required, Sold Separately: Chiller, 1 hp: We recommend #80-4003 (240V), 1 ph 50/60Hz or #80-4406
(380V), 1 ph 50/60Hz

Vacuum Pump: We recommend #70- 3121 (230V), 50/60Hz, UL or #70-3127 (230V, 50Hz, CE

Additional Kits Available, Sold Separately:
#10-1115 I Connection to Vacuum Pump #10-1106 I Connection to Vacuum Oven #10-1107 I

Connection to DrainDroyd
Dimensions: 89″ x 52″ x 47″ (HxWxD) Condenser;
Condenser Exchange Area: 21.6 ft2
Required Vacuum: 27 in. Hg
Number of Condensers: 1
Vacuum Pump;
Dimensions: 17″ x 7 .5″ x 12″ (LxWxH) Voltage: 120V, 3 FLA
Ultimate Vacuum Pressure (torr): 27.6 Chiller;
Dimensions: 27.6″ x 14.5″ x 22.6″
(LxWxH)

(INCLUDED) Vacuum Oven, 7.5 cu ft, 220V
7.5 cubic foot vacuum oven constructed for use in decarboxylation activation.
Equipped with 5 aluminum shelves spaced for biomass holding pans.
Configured to work in conjunction with United Science terpene traps for terpene collection and cannabinoid decarboxylation.

Electrical: 220V, 50/60Hz
Gerti cations: UL 61010-1, CSA, CE

Also Required:
#10-1023 Vacuum Oven Kit (60Hz) or #10-1065 Vacuum Oven Kit (SO Hz)
Pump Sold Separately

Vac Oven Pan SS304, 21 “x23”
Custom made for United Science. Stainless steel vacuum oven pans double capacity for decarboxylation, custom designed for cannabis processing.
21 “x23″, 18GA, 304SS, 2B Sold individually, 10 pans recommended for a single 7.5 cu ft vacuum oven. 3.25” deep

3 kg of biomass per pan x 5 pans per oven = 15kg per oven

Manufactured in USA for United Science

https://extraktlab.com/terptrap-equipment/

RQ-106
